Accessories (CTs, Shunt resistors, etc.)

Search by Keywords

Search by Keywords

Search Results
tuneRefine Results
CTschevron_right
Shunt resistors/Voltage dividers/Multiplierschevron_right
WF-N (Flux Meters)chevron_right
Current Loggerchevron_right

CTs

View Series Details

Window type CT

WCT-1
Terminal block type CT(Rated primary current:7.5A~150A、Rated secondary current:20mA)
Spec: Download(PDF)
WCT-2CR
Window type CT(Rated primary current:10A~750A、Rated secondary current:5A)
Spec: Download(PDF)

Clamp CT

CTL-□□CL
Clamp CT (Rated primary current:100~1000A)
Spec: Download(PDF)
CTL-10
Compact Split-core CT
Spec: Download(PDF)
WCTF-□□□A
Clamp Type CT (Current Transformer)
Spec: Download(PDF)

Cable

CTL-BUN
CT Connection Cable
Spec: Download(PDF)
CTL-EN
CT Extension Cable
Spec: Download(PDF)

Shunt resistors/Voltage dividers/Multipliers

View Series Details

Shunt resistors

WS-□
Shunt(Rated primary current:250A~750A、Rated secondary voltage:60mV)
Spec: Download(PDF)
ASH-400
Shunt(Rated secondary voltage:0.2V)
Spec: Download(PDF)
WS-1
Shunt(Rated primary current:less than 3A、Rated secondary voltage:60mV)
Spec: Download(PDF)
WS-2
Shunt(Rated primary current:3A~200A、Rated secondary voltage:60mV)
Spec: Download(PDF)

Voltage dividers

ADV-501/502
Voltage divider(Rated secondary voltage, :0.2V or 2V)
M-2-H
Voltage divider(Rated secondary voltage, :1V)
Spec: Download(PDF)

Multipliers

M-2
Multiplier (Rated secondary current : 1mA DC or 1.1mA AC)
Spec: Download(PDF)

WF-N (Flux Meters)

View Series Details

WF series

WF-N-1200-45
Flux meter
Spec: Download(PDF)
WF-N-1200-35
Flux meter
Spec: Download(PDF)
WF-N-0500-45
Flux meter
Spec: Download(PDF)

Current Logger

View Series Details

Accessories

CT-3
Clamp CT
WAR-100-502
Chart (for Grip-type electric current recorder)
WAR-H4.5R
Cartridge pen (for Grip-type electric current recorder)
